CLAA101ND06CW CPT 10.1" 1024*600 LCD PANEL
The CLAA101ND06CW is a 10.1-inch TN TFT-LCD module by Chunghwa Picture Tubes (CPT). It features 1024×600 resolution, 500 cd/m² brightness, 600:1 contrast, and an LVDS interface, suitable for industrial and automotive displays .
Price: $45.00 $40.00 / piece
Calculate shipping price
WINNI (HK) ELECTRONIC CO., LIMITED
+86 13827441621
Invshop168
RM 3, 27/F HO KING COMM CTR NO 2-16 FA YUEN ST MONG KOK KL
All Categories
- Industrial LCD display
-
Industrial Products
- DC Servo Drive
- AC Servo Drive
- other
- Heidelberg
- FANUC
- IFM
- Meter
- CCD
- Membrane Keypad
- Film
- YOKOGAWA Module
- Card
- ABB
- MITSUBISHI
- FANUC
- KEYENCE
- BECKHOFF
- Honeywell
- HOLLYSYS
- FUJI servo drives
- HP
- solenoid valve
- thermostat
- Siemens adapter
- color oscilloscope
- Fujitsu connector
- CHELIC
- SMC
- CISCO Module
- INTEL
- Key board
- FAIRCHILD
- Motherboard
- Board
- Bearing
- other
- Control Panel
- Contactor
- Circuit
- OMRON
- Relay
- Controller
- Photoelectric Switch
- Photoelectric Sensor
- Original
- Fan
- Motor Driver
- Limit Switch
- Amplifier
- power supply
- LENZE
- Cable
- Encoder
- Sensor
- Transformer
- Fiber Optic Sensor
- Protection Relay
- Temperature Controller
- Proximity Switch
- Switch Sensor
- Siemens
- Industrial board
- HMI Touch Glass
-
HMI Full Machine Whole unit
- OMRON HMI Touch Panel
- Siemens HMI Touch Panel
- Mitsubishi HMI Touch Panel
- Allen-Bradley automation HMI Touch Panel
- DELTA HMI Touch Panel
- EVIEW DELTA HMI Touch Panel
- KINCO DELTA HMI Touch Panel
- HITECH HMI Touch Panel
- WEINTECK HMI Touch Panel
- TECVIEW HMI Touch Panel
- WEINVIEW HMI Touch Panel
- PRO-FACE HMI Touch Panel
- SIMATIC HMI Touch Panel
- AMPIRE HMI Touch Panel
- HEIDELBERG HMI Touch Panel
- PANASONIC HMI Touch Panel
- PATLITE HMI Touch Panel
- KYOCERA HMI Touch Panel
- KEYENCE HMI Touch Panel
- WEINVIEW HMI Touch Panel
- HITECH HMI Touch Panel
- FUJI HMI Touch Panel
- HAKKO HMI Touch Panel
- SCHNEIDER HMI Touch Panel
- SAMKOON touch panel
- other
- Module
- lcd inverter
- Membrane Keypad Switch
- Winni Touch Screens
- Frequency Inverter
- Servo Motor
- PLC
CLAA101ND06CW CPT 10.1" 1024*600 LCD PANEL
CLAA101ND06CW Datasheets Download
Name: CLAA101ND06CW.pdfType
LCD PANEL
Brand
CPT
Model
CLAA101ND06CW
| Model: | CLAA101ND06CW | Panel-type: | a-Si TFT-LCD , LCM |
| Size: | 10.1 inch | Resolution: | 1024*600 |
| Active Area(mm): | 222.72(W)×125.28(H) mm | Response Time: | 25 (Typ.)(Tr+Td) |
| Brightness: | 500 cd/m² (Typ.) | Contrast Ratio: | 600:1 (Typ.) (TM) |
| Viewing Angle: | 70/70/70/50 (Typ.)(CR≥10) | Lamp Type: | 6S7P WLED , 30K hours , Without Driver |
| Refresh Rate: | 60Hz | Pixel Format: | RGB Vertical Stripe |
| Signal Interface: | LVDS (1 ch, 6/8-bit) , 60 pins FPC | Best View on: | 262K/16.2M 50% NTSC |
| Touch Screen: | without | Outline(mm): | 235(W)×143(H) ×4.8(D) mm |
| Model: | CLAA101ND06CW | Panel-type: | a-Si TFT-LCD , LCM |
| Size: | 10.1 inch | Resolution: | 1024*600 |
| Active Area(mm): | 222.72(W)×125.28(H) mm | Response Time: | 25 (Typ.)(Tr+Td) |
| Brightness: | 500 cd/m² (Typ.) | Contrast Ratio: | 600:1 (Typ.) (TM) |
| Viewing Angle: | 70/70/70/50 (Typ.)(CR≥10) | Lamp Type: | 6S7P WLED , 30K hours , Without Driver |
| Refresh Rate: | 60Hz | Pixel Format: | RGB Vertical Stripe |
| Signal Interface: | LVDS (1 ch, 6/8-bit) , 60 pins FPC | Best View on: | 262K/16.2M 50% NTSC |
| Touch Screen: | without | Outline(mm): | 235(W)×143(H) ×4.8(D) mm |
Customer's Reviews:
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Great
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Great deal! Would buy from again
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Excellent, many thanks
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
NO PROBLEM. GOOD WORK
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Fast delivery
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Worked Great
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Good quality products
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
good
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
item as described and packaged well
Price:
![]()
![]()
![]()
![]()
![]()
Quality:
![]()
![]()
![]()
![]()
![]()
Ease of use:
![]()
![]()
![]()
![]()
![]()
Delivery speed:
![]()
![]()
![]()
![]()
OverALL Rating:
![]()
![]()
![]()
![]()
04/20/2024, By
04/20/2024, By
Order received in good condition. Would definitely use this seller again for any future orders.
CLAA101ND06CW Summary
The CLAA101ND06CW is a 10.1-inch TFT-LCD module manufactured by Chunghwa Picture Tubes (CPT). It is designed as a robust solution for industrial and automotive applications .
Core Specifications:
Display: It features a 1024×600 (WSVGA) resolution and utilizes a TN (Twisted Nematic) panel in normally white mode, supporting up to 16.2 million colors.
Optics & Performance: The module offers a typical brightness of 500 cd/m² and a contrast ratio of 600:1, ensuring adequate visibility in various lighting conditions. The viewing angles are specified as 70/70/70/50 (L/R/U/D). The response time is 25ms .
Interface & Electrical: It connects via a 60-pin LVDS (1 channel, 6/8-bit) interface and operates at a standard 60Hz refresh rate. The power supply requires multiple voltages (e.g., 3.3V, 9.6V, 18.0V) .
Physical & Environmental: The module has an approximate weight of 285g, a matte surface finish, and a WLED backlight . It is designed to operate in a temperature range of -20°C to 70°C and can withstand vibrations up to 2.9G .
Core Specifications:
Display: It features a 1024×600 (WSVGA) resolution and utilizes a TN (Twisted Nematic) panel in normally white mode, supporting up to 16.2 million colors.
Optics & Performance: The module offers a typical brightness of 500 cd/m² and a contrast ratio of 600:1, ensuring adequate visibility in various lighting conditions. The viewing angles are specified as 70/70/70/50 (L/R/U/D). The response time is 25ms .
Interface & Electrical: It connects via a 60-pin LVDS (1 channel, 6/8-bit) interface and operates at a standard 60Hz refresh rate. The power supply requires multiple voltages (e.g., 3.3V, 9.6V, 18.0V) .
Physical & Environmental: The module has an approximate weight of 285g, a matte surface finish, and a WLED backlight . It is designed to operate in a temperature range of -20°C to 70°C and can withstand vibrations up to 2.9G .
